Teltonika TAP200 WiFi5 Access Point
, ,

Teltonika TAP200 WiFi5 Access Point (Wireless AP)

The Teltonika TAP200 Ceiling Mount WiFi 5 Access Point is equipped with dual-band technology, fast roaming, and an RJ45 port with PoE-in functionality. It’s designed to enhance WiFi coverage in medium-density spaces where high network performance is essential. The TAP200 features an integrated mounting bracket for quick and easy installation, and a sleek design to seamlessly blend into retail, enterprise, or any other environment.

TAP200 Key Features

  • Wave-2 802.11 b/g/n/ac Dual Band WiFi 5
  • Supporting speeds of up to 1000 Mbps and PoE-in functionality
  • UV-stabilised housing for lasting colour
  • Included a mounting bracket for quick setup
  • Free RMS Management access for 24 months

The TAP200 does not include a PSU or POE injector which will need to be ordered separately or it can be powered using a POE switch such as the Teltonika TSW200 unmanaged POE switch.

PDFTeltonika TAP200 Datasheet

£32.00 Excl VAT

CALL US to discuss volume pricing 01937 534914
Do you need a Fixed IP SIM Card?

Request A Quote Or Project Pricing

Wi-Fi 5 ACCESS POINT – TAP200

The TAP200 Teltonika Networks Access Point it’s WiFi 5 backward-compatible., perfect for strengthening Wi-Fi coverage in small enterprise and commercial spaces. This PoE-in access point can be powered by active PoE devices via its RJ45 port and was designed with simplicity and ease of installation in mind.

TAP200 Specification

WIRELESS

  • Wireless mode

    802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO)

  • Wi-Fi security

    WPA2-EAP/WPA3-EAP Mixed Mode, WPA3-EAP, WPA2-PSK/WPA3-SAE Mixed Mode, WPA3-SAE, OWE, WPA-PSK/WPA2-PSK Mixed Mode, WPA2-PSK, WPA2-EAP; AES-CCMP, TKIP, Auto Cipher modes, isolate clients

  • SSID/ESSID

    ESSID stealth mode (Hide SSID)

  • Wi-Fi users

    Up to 100 simultaneous connections

  • Wireless mesh/roaming

    Fast roaming (802.11r)

  • Wireless MAC filter

    Whitelist, blacklist

ETHERNET

  • Ethernet

    1 x RJ45 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover

NETWORK

  • Network protocols

    TCP, UDP, IPv4, IPv6, ICMP, HTTP, HTTPS, SSL/TLS, ARP, SSH, DHCP client, SMNP

SECURITY

  • Authentication

    SSH key based, HTTPS, CLI, IP & Login attempts block

  • VLAN

    Tag-based VLAN separation

MONITORING & MANAGEMENT

  • WEB UI

    HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, event log, system log, kernel log

  • FOTA

    Firmware update from server, automatic notification

  • SSH

    SSH (v1, v2)

  • JSON-RPC

    Management API over HTTP/HTTPS

  • RMS

    Teltonika Remote Management System (RMS)

SYSTEM CHARACTERISTICS

  • CPU

    MediaTek, Dual-Core, 880 MHz, MIPS 1004Kc

  • RAM

    256 MB, DDR3

  • FLASH storage

    16MB, SPI NOR Flash

FIRMWARE / CONFIGURATION

  • WEB UI

    Update FW from file, check FW on server, configuration profiles, configuration backup

  • FOTA

    Update FW

  • RMS

    Update FW/configuration for multiple devices at once

  • Keep settings

    Update FW without losing current configuration

FIRMWARE CUSTOMISATION

  • Operating system

    RutOS (OpenWrt based Linux OS)

  • Supported languages

    Busybox shell, Lua, C, C++

  • Development tools

    SDK package with build environment provided

POWER

  • Connector

    RJ45 Socket

  • Input voltage range

    44.0 – 57.0 V

  • PoE standards

    802.3af PoE Class 1

  • Power consumption

    Idle: < 4 W / Max: < 5.5 W

PHYSICAL INTERFACES

  • Ethernet

    1 x RJ45 port, 10/100/1000 Mbps

  • Status LEDs

    1 x Power LED (can be turned off from web-UI)

  • Antennas

    2 x Internal for 2.4 GHz Wi-Fi, 2 x Internal for 5 GHz Wi-Fi

  • Reset

    Reboot/User default reset/Factory reset button

PHYSICAL SPECIFICATION

  • Casing material

    UV stabilized plastic

  • Dimensions

    Ø 158 mm x 30 mm

  • Weight

    190 g

  • Mounting options

    AP Mounting Bracket (for ceiling mount)

OPERATING ENVIRONMENT

  • Operating temperature

    -40 °C to 75 °C

  • Operating humidity

    10% to 90% non-condensing

  • Ingress Protection Rating

    IP30

REGULATORY & TYPE APPROVALS

  • Regulatory

    CE, UKCA, FCC, IC, RCM, CB, EAC, UCRF, WEEE

EMC EMISSIONS & IMMUNITY

  • Standards

    EN 55032:2015+A11:2020

    EN 55035:2017+A11:2020

    EN 61000-3-3:2013+A1:2019+A2:2021

    EN IEC 61000-3-2:2019+A1:2021

    EN 301 489-1 V2.2.3

    EN 301 489-17 V3.2.4

  • ESD

    EN 61000-4-2:2009

  • RS

    EN IEC 61000-4-3:2020

  • EFT

    EN 61000-4-4:2012

  • Surge protection

    EN 61000-4-5:2014+A1:2017

  • CS

    EN 61000-4-6:2014

  • DIP

    EN IEC 61000-4-11:2020

RF

  • Standards

    EN 300 328 V2.2.2; EN 300 893 V2.1.1; EN 300 440 V2.2.1

SAFETY

  • Standards

    IEC 62368-1:2018

    EN IEC 62368-1:2020+A11:2020

    EN IEC 62311:2020

About WiFi Protocols and Standards

WiFi Standards and Features

WiFi 4
(802.11n)		 WiFi 5
(802.11ac)		 WiFi 6
(802.11ax)		 WiFi 6E
(802.11ax)
Range Good Excellent Excellent Excellent
Speed Poor Very Good Very Good Excellent
Capacity Poor Good Very Good Excellent
Security Good Good Excellent Excellent
Price Excellent Good Good Poor

Technical Features

WiFi 4
(802.11n)		 WiFi 5
(802.11ac)		 WiFi 6
(802.11ax)		 WiFi 6E
(802.11ax)
MU-MIMO No Download Only Upload & Download Upload & Download
OFDMA No No Yes Yes
Security WPA-2 WPA-2 WPA-3 WPA-3
Max QAM 64 256 1024 1024
Max Channel 40MHz 160MHz 320MHz 320MHz
Spatial Stream 300Mbps 433Mbps 600Mbps 600Mbps
Max Speed 600Mbps 3.4Gbps 10.8Gbps 20.4Gbps
Frequency 2.4GHz 2.4GHz, 5GHz 2.4GHz, 5GHz 2.4GHz, 5GHz, 6GHz

Powering the Teltonika TAP200 WiFi Access Point

You can use the Teltonika PR322UK7 POE Injector if you want a simple, low cost POE solution or can connect to the TAP200 to one of Teltonika POE Switches.
