Teltonika TSW101 POE Switch


Teltonika TSW101 POE+ Network Switch – Gigabit Power Over Ethernet Switch

  • 5 x Gigabit ports (4 x POE Ports 802.3af and 802.3at)
  • Rugged aluminium housing
  • Compact size with DIN rail mounting option
  • Wide range of supported power supply voltages – 9-30V
  • Plug-n-play No additional configuration needed

£44.00 Excl VAT

Do you need a Fixed IP SIM Card?

CALL US to discuss volume or project pricing 01937 534914

Teltonika TSW101 is a robust industrial grade POE switch with 5x Gigabit Ethernet ports, 4 of which can be used to power connected devices via PoE 802.3af/802.3at standards, and a 2-pin power socket for automotive applications.





Teltonika TSW101 – power consumption table

Test type
Current (mA)
Power consumption (W)
Idle (9 V)
26
0.31
Idle (12 V)
20
0.48
Idle (24 V)
15
0.64
Test type
Current (mA)
Power consumption (W)
5 LAN devices connected + heavy data traffic1 (9 V)
148
1.82
5 LAN devices connected + heavy data traffic1 (12 V)
82
1.93
5 LAN devices connected + heavy data traffic1 (24 V)
52
2.31
Test type
Current (mA)
Power consumption (W)
1 LAN and 4 PoE devices (RUTX08, RUTX10, RUTX11, RUTX12) connected + heavy data traffic1 (12 V)
388
19.40
1 LAN and 4 PoE devices (RUTX08, RUTX10, RUTX11, RUTX12) connected + heavy data traffic1 (24 V)
343
19.55
Test type
Current (mA)
Power consumption (W)
4 PoE dummy loads connected (30 W each) (24 V)
4691
112.58

1 – Data streams between devices were created using iPerf.
Power consumption may differ due to connected devices, testing environment and conditions.
