Proroute RAPID NR550 high speed 5G router

Meet RAPID NR550, the first in the new range of high speed 5G cellular communications solutions from Proroute.  The NR550 Industrial 5G Router is a multi-purpose, high speed 5G router that caters for the widest scope of 5G Internet connectivity requirements.

Good looking enough to be used as a home or office 5G router and also meet the demands of office and home 5G connectivity with 4×4 MiMo cellular connectivity to provide some of the fastest 5G connection speeds in an industrial 5G router and Gigabit Ethernet and dual band, intelligent WiFi to deliver long range, high speed wireless connectivity for the demands of home and office life.  The NR550 router also has industry standard SMA antenna connectors so can utilise external 5G antennas.

The RAPID NR550 is also a very practical and durable solution for many M2M applications delivering a reliable 5G connection with ping reboot and intelligent cellular keep alive features built-in, along with all the usual features such as port forwarding and secure VPN connectivity as well as the dual SIM failover option to use a back-up SIM / Network in the event of the primary SIM / Network being unavailable.  If you really need it, the NR550 has the console port to provide RS232 connectivity and even comes supplied with a serial interface cable as well as both magnetic mount and high gain paddle antennas for the 5G modem.  If these antennas don’t suit your installation requirements, especially for remote management and monitoring applications where you may need hole mounted, magnetic mounted, roof mounted and outdoor 5G antennas then the RAPID NR550 has standard SMA antenna connectors so can easily use alternative 5G antennas.

All in all, the Proroute RAPID NR550 is a reliable, practical and secure 5G Internet connectivity device for home, office and M2M applications.

Proroute NR550 Industrial 5G Router

Embedded, Industrial 5G modem provides up to 2.1Gbps Download Speed and up to 900Mbps Upload Speed using 5G SIM
Dual band 802.11AC WiFi (2.4Ghz and 5Ghz) with peak data transfer of 866Mbps - WiFi hotspot supports up to 50 users.
The dual SIM feature enables a backup SIM to be used by the RAPID NR550 router to provide extra 5G network resilience for M2M remote access and monitoring applications.
5G network monitoring ensures consistent 5G connection with secure firewall and robust electrical and mechanical structure ensuring reliability
NR550 – Industrial design, high and low temperature resistance, durable casing.
The design and manufacture of the Proroute RAPID NR550 ensures reliable and hassle free performance.  With high-grade 32 bit processors and industrial grade wireless and 5G cellular modules, this router is designed to ensure long term, stable, secure and reliable connectivity for the long term.
Rugged metal casing, high protection level, wide temperature and pressure, EMC level 4, the NR550 can withstand harsh conditions such as extreme temperature, unstable voltage, high electromagnetic radiation and dust to ensure continuous communication between remote equipment and monitoring centre.
Multi-antenna design to improve data transmission and reception capabilities
Externally widened 4 high-performance antennas, through scientific layout, in a limited space, to achieve greater isolation between the same frequency antennas, effectively reduce the same frequency interference, and improve data transmission and reception capabilities.
Industrial 5G

Industrial 5G Router providing high performance with rugged good looks connectivity resilience and functionality for a wide range of applications.  Suitable for M2M remote access and monitoring as well as home and office 5G connectivity.

  • High-performance industrial-grade wireless module
  • High-performance industrial-grade 32-bit communication processor
  • Metal shell, protection grade IP30.Metal housing and system safety isolation
  • Wide power input DC 9~36V
  • Flash  : Nor flash 16MB NAND flash 128MB
  • DDR3 : 512MB
  • Multiple WAN connection methods, include static IP, DHCP, PPPOE,
    3G/UMTS/4G/LTE, DHCP-4G/5G
  • Remote management SYSLOG/SNMP/TELNET/SSH/HTTPS
  • Support local upgrade and remote upgrade, import and export configuration files
  • NTP / Built in RTC
  • MAC address clone
  • Operating Temperature -35~+75ºC(-31~+167℉)
  • Storage Temperature -40~+85ºC(-40~+185℉)
  • Relative Humidity 95% (No condensation)
5G Processor

5G Modem – Asia/Europe/Australia (excludes China) support boths 5G SA and NSA network architectures with faster transmission speed, better carrying capacity, and lower network latency. Supports the 5G NR Sub6 band, and is compatible with LTE and WCDMA standards.

  • 5G Sub-6 Bands : n1/3/5/7/8/20/28/38/40/41/77/78/79
  • LTE FDD Bands : B1/3/5/7/8/18/19/20/28/32
  • LTE TDD Bands : B38/40/41/42/43
  • WCDMA Bands : B1/3/5/8/19
  • MIMO: 5G NR DL – 4x4MIMO: n1/3/7/38/40/41/77/78/79
  • MIMO: 5G NR UL – 2x2MIMO: n41/77/78/79
  • MIMO: LTE DL – 4x4MIMO: B1/3/7/32/38/40/41/42/43
  • MIMO: LTE UL – 1×1 MIMO
  • NR SA – 2.1Gbps(DL) / 900Mbps(UL)
  • NR ENDC – 2.5Gbps(DL) / 600Mbps(UL)
  • LTE – 1Gbps(DL) / 150Mbps(UL)
  • WCDMA – 42Mbps(DL) / 5.76Mbps(UL)

Hardware download and upload speeds are maximum theoretical and will depend upon 4G/5G network provider, distance to base station, environment and network throttling / prioritisation / contention.

WiFi
  • 802.11AC/g/g/n WiFi Dual Band
  • 2.412GHz to 2.472GHz and 5.150GHz to 5.825GHz, simultaneous dual band
  • 2×2 MU-MIMO On-board WiFi 2.4GHz radio, up to 400Mbps physical data rate
  • 2×2 MU-MIMO On-board WiFi 5GHz radio, up to 866Mbps physical data rate
  • Intelligent, combined dual band WiFi antennas supporting both 2.4Ghz and 5.0Ghz ranges
  • AP /AP Client/bridge mode supported
  • WEP, WPA, WPA2 encryption
  • Power : 26dBm (11b), 21dBm (11ac/MCS7/HT40), 20dBm (11ac/MCS9/HT80)
  • Sensitivity : <-72dBm@54Mbps
  • Supports up to 50 WiFi Users
VPN

VPNVirtual Private Network  is a method of connecting multiple private networks across the Internet.

VPNs can serve to achieve many different goals, but some of its main purposes are:

  • access between remote private networks;
  • data encryption;
  • anonymity when browsing the Internet.

NR550 router has built-in VPN Server / Client Functionality as standard.

  • Supports Open VPN / PPTP / L2TP / IPSEC
  • Supports GRE Tunnelling
  • Supports up to 5 simultaneous IPSEC tunnels
RS232

RS232 Interface

NR550 has RS232 port and is supplied with RS232 Serial Cable

  • 1 x RS232 , Built in 15KV ESD:
  • Data bit:5, 6, 7, 8
  • Stop bit:1, 1.5 (Optional), 2
  • Check:NONE, ODD, EVEN, SPACE (Optional) and MARK (Optional)
  • Baud rate :2400~115200bits/s

Proroute NR550 5G Router Front Panel has RP-SMA Antenna connectors for WiFi, LED indicators, Dual SIM Slots, 40 x 10/1000/1000 Ethernet Ports, 10/100/1000 WAN Port, RS232 Console Port, RESET Button and Power Connector (2.1mm). Power is 5-36VDC 1.5AMP.

NR550 5G Router Ethernet Ports

The RAPID NR550 does not support POE for power so if you need to provide power to the router using POE then we recommend using the Gigabit POE Splitter which will split a POE feed into 2.1mm jack plug 12VDC and Gigabit Ethernet connector for data.

The rear of the NR550 router has 4 x SMA Female Connectors for the 5G Cellular Antennas.  The unit is supplied with paddle antennas as well as optional magnetic mount antennas and can also support a range of 4×4 MiMo 5G Antennas such as directional 5G antenna and Roof Mount / Puck Antenna.
